| Ref # | Current Part Nbr |
Description | Superceded From |
Status | Notes | List Price |
Online Price |
Quan Used |
Order Quan |
|---|---|---|---|---|---|---|---|---|---|
| 1 | 88302A1 | GIMBAL RING ASSY | 77124A2 | SS/NLA |
|
$0.00 | $0.00 | 1 | |
| 1 | 94993A7 | GIMBAL RING ASSY | 88343A2 | SS |
|
$1,053.49 | $943.38 | 1 | |
| 2 | 32538 | ----BEARING ROLLER - GIMBAL RING | ACT | $9.98 | $9.74 | 1 | |||
| 3 | 32541 | ----SEAL GIMBAL RING | ACT | $18.99 | $18.58 | 2 | |||
| 4 | 39273 | ----SLEEVE GIMBAL RING | ACT | $18.99 | $18.53 | 1 | |||
| 5 | 69059 | ----FITTING-GR GREASE - GIMBAL RING (1/8-27) | NLA |
|
$0.00 | $0.00 | 1 | ||
| 5A | 8M0169589 | FITTING GIMBAL RING (1/4-28) | 74036 | SS |
|
$4.79 | $4.69 | 2 | |
| 6 | 77633Q | LUBRICAP GIMBAL RING GREASE FITTING | 29359 | SS |
|
$6.99 | $6.83 | 3 | |
| 7 | 77123 | PIN-HINGE THREADED (WITH GREASE GROOVE) | ACT | $32.39 | $31.75 | 2 | |||
| 8 | 64947 | DUMMY SENDER DUMMY | ACT |
|
$22.99 | $22.51 | 1 | ||
| 8 | 805320A03 | TRIM SWITCH ASSY TRIM LIMIT | 88678A5 | SS |
|
$176.99 | $159.19 | 1 | |
| 9 | 19280 | HARNESS DUMMY SENDER | 70967 | SS/NLA |
|
$0.00 | $0.00 | 1 | |
| 9 | 19292 | HARNESS TRIM LIMIT SWITCH | 70968 | SS/NLA |
|
$0.00 | $0.00 | 1 | |
| 10 | 46942 | SCREW HARNESS ATTACHING | ACT |
|
$1.10 | $1.08 | 2 | ||
| 10 | 63400 | SCREW HARNESS ATTACHING | NLA |
|
$0.61 | $0.60 | 2 | ||
| 11 | 63990 | INSULATOR SWITCH AND SENDER | ACT | $8.19 | $8.00 | 2 | |||
| 12 | 37978 | SCREW AND SENDER TO GIMBAL RING | ACT | $3.39 | $3.30 | 4 | |||
| 13 | 26996 | LOCKWASHER SWITCH AND SENDER SCREW | ACT | $1.20 | $1.18 | 4 | |||
| 14 | 57008 | RETAINER SWITCH AND SENDER SCREW | ACT | $3.99 | $3.91 | 4 | |||
| 15 | 88771A1 | LEVER ASSY | 66546A1 | SS/NLA |
|
$0.00 | $0.00 | 1 | |
| 15A | 52698 | ----SLEEVE STEERING LEVER | NLA |
|
$0.00 | $0.00 | 1 | ||
| 15 | 88771A1 | LEVER | 88771 | SS/NLA |
|
$0.00 | $0.00 | 1 | |
| 15 | 88433 | LEVER | 66545 | SS/NLA |
|
$0.00 | $0.00 | 1 | |
| 15 | 88433 | LEVER | NLA |
|
$0.00 | $0.00 | 1 | ||
| 16 | 88302A1 | ORD 88302A 1 UPPER SWIVEL | 65537 | NLA |
|
$0.00 | $0.00 | 1 | |
| 16 | 88302A2 | SHAFT ASSY UPPER SWIVEL | NLA |
|
$399.30 | $376.03 | 1 | ||
| 17 | 72413 | RING UPPER SWIVEL SHAFT | NLA |
|
$0.00 | $0.00 | 1 | ||
| 18 | 8M2014641 | NUT UPPER SWIVEL SHAFT | 25599 | SS |
|
$17.89 | $17.46 | 1 | |
| 19 | 8M0204652 | PLUG UPPER SWIVEL SHAFT | 32561 | SS |
|
$6.79 | $6.64 | 1 | |
| 20 | 85344 | WASHER UPPER SWIVEL SHAFT | ACT | $2.79 | $2.72 | 1 | |||
| 20 | 32997 | WASHER UPPER SWIVEL SHAFT (.063) | NLA |
|
$0.00 | $0.00 | 1 | ||
| 21 | 807204 | SCREW STEERING LEVER TO UPPER SWIVEL SHAFT | 32995 | SS |
|
$4.49 | $4.39 | 1 | |
| 22 | 8M2008293 | NUT STEERING LEVER TO UPPER SWIVEL SHAFT SCREW | 79857 | SS |
|
$1.20 | $1.18 | 1 | |
| 23 | 68291A2 | LINK ROD ASSY | NLA |
|
$0.00 | $0.00 | 1 | ||
| 24 | 52698 | ----SLEEVE STEERING LINK ROD | NLA |
|
$0.00 | $0.00 | 1 | ||
| 25 | 20086 | ----WASHER STEERING LINK ROD | ACT |
|
$1.70 | $1.66 | 1 | ||
| 26 | 46132 | ----WASHER STEERING LINK ROD (1/8" THICK) | ACT |
|
$3.19 | $3.11 | 1 | ||
| 27 | 55438 | ----NUT STEERING LINK ROD | ACT |
|
$2.19 | $2.14 | 2 | ||
| 28 | 45882 | ----COTTER PIN STEERING LINK ROD | ACT |
|
$2.96 | $2.90 | 2 | ||
| 29 | 78790A6 | LINK ROD ASSY | 78790A4 | SS/NLA |
|
$0.00 | $0.00 | 1 | |
| 30 | 87738A1 | ----BOLT ASSY LEVER TO LINK ROD | NLA |
|
$0.00 | $0.00 | 1 | ||
| 33 | 20086 | ----WASHER STEERING LINK ROD | ACT |
|
$1.70 | $1.66 | 1 | ||
| 34 | 82671013 | ----NUT LINK ROD SCREW | 34932 | SS |
|
$4.69 | $4.59 | 1 | |
| 34A | 55438 | ----NUT STEERING LINK ROD | ACT |
|
$2.19 | $2.14 | 1 | ||
| 35 | 45882 | ----COTTER PIN LINK ROD AND SCREW | ACT |
|
$2.96 | $2.90 | 2 | ||
| 35A | 87739 | ----SPRING LINK ROD SCREW | NLA |
|
$0.00 | $0.00 | 1 | ||
| 36 | 79146 | RETAINER CONNECTOR, TRIM LIMITS LEADS | ACT | $5.59 | $5.47 | 2 | |||
| 37 | 88432 | SCREW GIMBAL RING | ACT |
|
$99.99 | $93.78 | 2 | ||
| 38 | 34931 | WASHER GIMBAL RING SCREW | ACT |
|
$2.59 | $2.53 | 4 | ||
| 39 | 82671013 | NUT GIMBAL RING SCREW | 34932 | SS |
|
$4.69 | $4.59 | 2 | |
| - | 805320A03 | TRIM SENDER ASSY | 88678A4 | SS |
|
$176.99 | $159.19 | 1 | |
| - | 805130A6 | TRIM SENDER KIT | 88678A6 | SS |
|
$120.73 | $108.86 | 1 |
