| Ref # | Current Part Nbr |
Description | Superceded From |
Status | Notes | List Price |
Online Price |
Quan Used |
Order Quan |
|---|---|---|---|---|---|---|---|---|---|
| 1 | 823907T12 | CARBURETOR (WMC-52A) (20 Hp) | 823907T5 | SS/NLA |
|
$0.00 | $0.00 | 1 | |
| 1 | 823907T12 | CARBURETOR (WMC-64) (20 Hp) | 823907T9 | SS/NLA |
|
$0.00 | $0.00 | 1 | |
| 1 | 823907A16 | CARBURETOR KIT (WMC-85) (20Hp) | NLA |
|
$0.00 | $0.00 | 1 | ||
| 1 | 817405T23 | CARBURETOR (WMC-53A) (25Hp/Jet 20) | 817405T11 | SS/NLA |
|
$0.00 | $0.00 | 1 | |
| 1 | 817405T23 | CARBURETOR (WMC-65) (25Hp/Jet 20) | 817405T16 | SS/NLA |
|
$0.00 | $0.00 | 1 | |
| 1 | 817405T23 | CARBURETOR KIT (WMC-87) (25 Hp/Jet 20) | 817405A22 | NLA |
|
$0.00 | $0.00 | 1 | |
| 2 | 815133 | ----VALVE Throttle | NLA |
|
$0.00 | $0.00 | 1 | ||
| 2 | 96461 | ----VALVE Throttle | ACT |
|
$3.80 | $3.71 | 1 | ||
| 3 | 96951 | ----SHAFT Throttle | NLA |
|
$0.00 | $0.00 | 1 | ||
| 4 | 8M0138645 | --------SCREW | ACT | $0.80 | $0.79 | 1 | |||
| 5 | 804996 | --------SPRING | NLA |
|
$0.00 | $0.00 | 1 | ||
| 6 | 803861 | ----VALVE Inlet Needle | ACT | $25.42 | $25.00 | 1 | |||
| 7 | 7394 | ----JET (.044) | ACT |
|
$4.10 | $4.00 | 1 | ||
| 7 | 3796 | ----JET (.076) | ACT |
|
$4.10 | $4.00 | 1 | ||
| 8 | 9171 | ----PLUG | ACT | $8.90 | $8.68 | 1 | |||
| 9 | 823648 | ----COVER Diaphragm | NLA |
|
$0.00 | $0.00 | 1 | ||
| 10 | 9697 | ----SCREW | NLA |
|
$0.00 | $0.00 | 4 | ||
| 11 | 9702 | ----BODY | 15827A1 | NLA |
|
$0.00 | $0.00 | 1 | |
| 12 | 9643 | ----SCREW | ACT | $4.99 | $4.88 | 5 | |||
| 13 | 96371 | ----COVER Fuel Pump | NLA |
|
$0.00 | $0.00 | 1 | ||
| 14 | 9762 | ----PLUG | NLA |
|
$0.00 | $0.00 | 1 | ||
| 15 | 97611 | ----GASKET/DIAPHRAGM KIT | ACT | $87.92 | $84.69 | 1 | |||
| 16 | 8237072 | ----REPAIR KIT | ACT | $136.58 | $127.50 | 1 | |||
| 17 | 9699 | ----PLATE Manual | NLA |
|
$0.00 | $0.00 | 1 | ||
| 18 | 823433 | ----CHOKE Electric | NLA |
|
$0.00 | $0.00 | 1 | ||
| 19 | 9696 | ----SCREW | NLA |
|
$0.00 | $0.00 | 2 | ||
| 20 | 192061 | ----GASKET Carburetor | ACT |
|
$4.99 | $4.88 | 1 | ||
| 21 | 9635 | ----DIAPHRAGM/GASKET | ACT | $46.00 | $45.17 | 1 | |||
| 22 | 9633 | ----GASKET | ACT | $5.20 | $5.08 | 1 | |||
| 23 | F10064 | ----SHAFT | ACT | $4.60 | $4.49 | 1 | |||
| 24 | 824401 | ----LEVER Float | ACT | $7.10 | $6.93 | 1 | |||
| 25 | 9844A1 | ----SERVICE KIT Primer/Injector | ACT |
|
$39.99 | $39.28 | 1 | ||
| 26 | 9164 | ----BOWL Fuel | ACT | $88.92 | $85.53 | 1 | |||
| 27 | 91691 | ----FLOAT | ACT | $13.59 | $13.31 | 1 | |||
| 28 | 44426 | ----GASKET | ACT | $7.80 | $7.61 | 1 | |||
| 29 | 5902 | ----SCREW (#6-32 x .187) | NLA |
|
$0.00 | $0.00 | 1 | ||
| 30 | 40019111 | SCREW (M5 x 35) | ACT | $1.10 | $1.08 | 1 | |||
| 31 | 400211 | NUT (M5) Stainless Steel | ACT | $3.60 | $3.52 | 1 | |||
| - | 41499A88 | GASKET SET | 41499A87 | SS |
|
$143.00 | $134.67 | 1 | |
| - | 804946T02 | POWERHEAD ASSEMBLY |
|
$0.00 | $0.00 | 1 |
