| Ref # | Current Part Nbr | Description | Superceded From | Status | Notes | List Price | Online Price | Quan Used | Order Quan |
|---|---|---|---|---|---|---|---|---|---|
| 1 | 42213A24 | SWIVEL HEAD | ACT |  | $346.25 | $326.07 | 1 | ||
| 1 | 42213A25 | SWIVEL HEAD | NLA | | $182.40 | $171.76 | 1 | ||
| 2 | 823939 | BUSHING | ACT | $19.30 | $18.82 | 2 | |||
| 3 | 822147 | PLATE Tiller Handle | NLA | | $9.10 | $8.94 | 1 | ||
| 3 | 8221471 | PLATE | ACT | | $10.60 | $10.34 | 1 | ||
| 4 | 40011107 | SCREW (M5 x 16) Stainless | ACT | $1.70 | $1.66 | 2 | |||
| 4 | 4006731 | SCREW (M6 x 16) | ACT | $2.80 | $2.74 | 2 | |||
| 5 | 822145 | WASHER | ACT | $2.40 | $2.35 | 2 | |||
| 6 | 826792 | WAVE WASHER | ACT | $8.50 | $8.29 | 1 | |||
| 7 | 822146 | WASHER | ACT | $17.30 | $16.87 | 1 | |||
| 8 | 821468A66 | ARM ASSEMBLY Steering Handle | 821468A8 | SS | | $184.92 | $174.14 | 1 | |
| 8 | 821468A66 | ARM ASSEMBLY Steering Handle | 821468A9 | SS | | $184.92 | $174.14 | 1 | |
| 9 | 822441 | RETAINER | ACT | $3.50 | $3.42 | 1 | |||
| 10 | 40011107 | SCREW (M5 x 16) Stainless | ACT | $1.70 | $1.66 | 1 | |||
| 11 | 822148A3 | COVER KIT | ACT | | $105.58 | $99.43 | 1 | ||
| 11 | 822148A2 | COVER KIT | ACT | | $82.17 | $79.03 | 1 | ||
| 12 | 822150 | ----PULLEY | ACT | $33.92 | $33.31 | 1 | |||
| 13 | NSS | --------NOT SOLD SEPARATE Pulley Case (PART OF REF. #11) | | $0.00 | $0.00 | 1 | |||
| 14 | 878608 | ----SCREW (#10-16 x .500) | 812832 | SS | | $1.60 | $1.57 | 1 | |
| 15 | 43242T09 | ----CABLE Throttle | 432429 | SS | | $44.67 | $43.86 | 2 | |
| 15 | 432426 | ----CABLE Throttle | ACT | | $31.00 | $30.44 | 2 | ||
| 16 | 9600910 | ----SLEEVE | ACT | | $1.50 | $1.47 | 1 | ||
| 16 | 960099 | ----SLEEVE (12.00 Inches) | ACT | | $1.60 | $1.57 | 1 | ||
| 17 | 8242002 | DECAL | ACT | | $13.30 | $12.97 | 1 | ||
| 17 | 8242004 | DECAL | 8242001 | SS | | $13.30 | $12.97 | 1 | |
| 18 | 8M0221732 | GRIP | 99589 | SS | | $21.58 | $21.20 | 1 | |
| 19 | 8M0104615 | SWITCH ASSEMBLY Stop | 823609A1 | SS | | $57.50 | $55.31 | 1 | |
| 20 | 821972T | KNOB Throttle | 821972 | SS | | $17.90 | $17.46 | 1 | |
| 21 | 892995 | LOCK Throttle | 821971 | SS | | $7.50 | $7.32 | 1 | |
| 22 | 8M0204707 | SCREW (M6 x 25) | 4000330 | SS | | $3.80 | $3.71 | 1 | |
| 23 | 822429 | HANDLE Throttle | ACT | | $16.00 | $15.61 | 1 | ||
| 23 | 821465 | HANDLE Throttle | ACT | | $25.50 | $25.04 | 1 | ||
| 24 | 821463T01 | TILLER TUBE | 821463A1 | SS | | $93.75 | $90.17 | 1 | |
| 25 | 96203 | SPRING | ACT | $4.00 | $3.91 | 1 |
