Ref # Current
Part Nbr		 Description Superceded
From		 Status Notes List
Price		 Online
Price		 Quan
Used		 Order
Quan
1 863489 HOSE Tansmission Cooler to Check Valve ACT $88.99 $83.82 1
2 864206A1 CHECK VALVE ACT $68.49 $64.43 1
3 863623 HOSE Check Valve to Fuel Cooler ACT $47.99 $47.00 1
4 864551 HOSE Intake Bypass to Circulating Pump ACT $20.39 $19.97 1
5 864431 HOSE Distribution Fitting to Heat Exchanger ACT $52.99 $49.92 1
6 864539 HOSE Thermostat Housing to Upper Manifold ACT $29.69 $29.13 1
6 864539 HOSE Thermostat Housing to Upper Manifold ACT $29.69 $29.13 1
6 864956 HOSE Thermostat Housing to Upper Manifold ACT $39.99 $39.20 1
7 864552 HOSE Thermostat Housing to Upper Manifold ACT $32.79 $32.16 1
7 864552 HOSE Thermostat Housing to Upper Manifold ACT $32.79 $32.16 1
7 864954 HOSE Thermostat Housing to Upper Manifold ACT $62.49 $58.70 1
8 864509 HOSE ACT $63.49 $59.65 1
9 864508 HOSE Port Manifold Drain ACT $47.49 $46.50 1
10 863670 HOSE Fuel Cooler to Accumulator Housing ACT $35.49 $34.82 1
11 864506 HOSE Heat Exchanger to Thermostat Housing ACT $19.59 $19.23 1
12 864507 HOSE Heat Exchanger to Thermostat Housing ACT $18.39 $18.01 1
13 8M2005027 HOSE Heat Exchanger to Starboard Elbow ACT $25.49 $24.96 1
13 8M2005027 HOSE Heat Exchanger to Starboard Elbow ACT $25.49 $24.96 1
13 864955 HOSE Heat Exchanger to Starboard Elbow ACT $40.92 $40.18 1
13 864544 HOSE Heat Exchanger to Starboard Elbow ACT $52.99 $49.87 1
13 8M2005027 HOSE Heat Exchanger to Starboard Elbow ACT $25.49 $24.96 1
13 864544 HOSE Heat Exchanger to Starboard Elbow ACT $52.99 $49.87 1
13 864544 HOSE Heat Exchanger to Starboard Elbow ACT $52.99 $49.87 1
13 864974 HOSE Heat Exchanger to Starboard Elbow ACT $19.99 $19.56 1
14 864726 HOSE Heat Exchanger to Port Elbow ACT $39.49 $38.79 1
14 864726 HOSE Heat Exchanger to Port Elbow ACT $39.49 $38.79 1
14 864953 HOSE Heat Exchanger to Port Elbow NLA $0.00 $0.00 1
14 864543 HOSE Heat Exchanger to Port Elbow ACT $52.49 $49.29 1
14 864726 HOSE Heat Exchanger to Port Elbow ACT $39.49 $38.79 1
14 864543 HOSE Heat Exchanger to Port Elbow ACT $52.49 $49.29 1
14 864543 HOSE Heat Exchanger to Port Elbow ACT $52.49 $49.29 1
14 864973 HOSE Heat Exchanger to Port Elbow ACT $20.49 $20.13 1
15 863611 HOSE Sea Pump to Trans Cooler ACT $81.49 $76.68 1
16 815504212 CLAMP Hose ACT $5.89 $5.76 1
17 815504216 CLAMP Hose ACT $18.69 $18.24 1
18 8M0188622 CLAMP Hose 815504222 SS $5.69 $5.56 1
19 815504228 CLAMP Hose ACT $17.29 $16.94 1
20 815504232 CLAMP Hose ACT $8.89 $8.68 1
21 864886 HOSE Heat Exchanger to Circulating Pump 864432 SS $45.99 $45.19 1
22 815504220 CLAMP Hose ACT $7.59 $7.42 1
23 864395T01 HEAT EXCHANGER Closed Cooling 864395T SS $4,007.99 $3,589.71 1
24 864708 ----COVER-HEAT EX. End, Heat Exchanger ACT $104.99 $94.44 2
25 818679 ----O-RING ACT $8.19 $8.00 4
26 94247 ----SCREW ACT $1.50 $1.47 2
27 8M0084884 ----SEAL End Cover 864707 SS $15.89 $15.51 2
28 8148791 CAP-PRESSURE Pressure ACT $60.49 $56.97 1
29 805559 SCREW ACT $10.29 $10.05 1
30 34353 SCREW ACT $2.59 $2.53 3
31 815504396 CLAMP Heat Exchanger ACT $23.79 $23.33 1
32 71587A10 RECOVERY KIT ACT $97.49 $91.59 1
NS 774572 ----HOSE-48 INCH ACT $70.49 $66.16 1
33 71587A11 ----BOTTLE ASSY Coolant Recovery Kit ACT $74.99 $70.32 1
34 72058 --------CAP Coolant Recovery Bottle ACT $11.29 $11.02 1
35 8M0062666 HOSE-96 INCH Sea Water Pump to Water Pick UP 1743579 SS $220.99 $199.09 1
36 18431 PAD Heat Exchanger ACT $34.99 $34.37 1
37 864429T BRACKET Cooler ACT $399.99 $360.53 1
38 8M0171028 HOSE 864533 SS $30.69 $30.12 1
39 862993 FITTING-WATER Drain ACT $5.59 $5.47 1
40 8M0119211 PLUG KIT 806608A1 SS $10.19 $9.95 1
41 32509 ----O RING ACT $2.39 $2.33 1
NS 8M0074364 COVER-.375 Hose Clamp End 8079923 SS $3.29 $3.21 A/R
