| Ref # | Current Part Nbr |
Description | Superceded From |
Status | Notes | List Price |
Online Price |
Quan Used |
Order Quan |
|---|---|---|---|---|---|---|---|---|---|
| 1 | 12020A3 | HANDLE ASSEMBLY Steering Arm Black | 12020A1 | SS |
|
$232.67 | $219.11 | 1 | |
| 1 | 12020A3 | ARM ASSEMBLY Steering Gray | 12020A2 | SS |
|
$232.67 | $219.11 | 1 | |
| - | 8M0169589 | ----FITTING Grease | 74036 | SS |
|
$4.80 | $4.69 | 1 | |
| 2 | 12018A4 | TUBE ASSEMBLY | 12018A2 | SS |
|
$255.33 | $240.45 | 1 | |
| 3 | 48414 | HOUSING | ACT | $41.16 | $40.43 | 1 | |||
| 4 | 48519 | PLATE | ACT | $20.17 | $19.81 | 1 | |||
| 5 | 48518 | GASKET | ACT | $5.50 | $5.37 | 1 | |||
| 6 | 72169 | SCREW (#10-24 x .500) | ACT | $1.10 | $1.08 | 5 | |||
| 6 | 878608 | SCREW (#10-16 x .500) | 812832 | SS |
|
$1.70 | $1.66 | 5 | |
| 7 | 889729 | CLAMP | 12013 | SS |
|
$15.30 | $14.92 | 1 | |
| 8 | 40007112 | SCREW (M5 x 40) | ACT | $3.70 | $3.61 | 2 | |||
| 9 | 816874 | WING NUT | 816873 | SS |
|
$5.10 | $4.98 | 1 | |
| 10 | 823609A15 | SWITCH KIT Stop - Throttle Handle | ACT |
|
$51.75 | $49.78 | 1 | ||
| 11 | 8M0104612 | ----SWITCH ASSEMBLY Stop Design II, With Metal Lock Ting | 823609A5 | SS |
|
$38.50 | $37.81 | 1 | |
| 12 | NLA | No Longer Available Stop Switch, Design I, Odres Kit 87-823609A15 |
|
$0.00 | $0.00 | 1 | |||
| 13 | 62568 | SCREW (#10-16 x .375) | ACT | $1.10 | $1.08 | 1 | |||
| 14 | 8M0221732 | GRIP | 99589 | SS |
|
$22.42 | $22.02 | 1 | |
| 15 | 648552 | CLAMP | 64855 | SS |
|
$4.80 | $4.69 | 2 | |
| 16 | 878609 | SCREW (#10-16 x .600) | 8128321 | SS |
|
$2.60 | $2.54 | 1 | |
| 17 | 8885242 | CONDUIT | 785512 | SS/NLA |
|
$0.00 | $0.00 | 1 | |
| 18 | 8M0026078 | GUIDE TUBE | 895661 | SS/NLA |
|
$0.00 | $0.00 | 1 | |
| 19 | 89578 | BARREL | ACT | $48.08 | $47.22 | 1 | |||
| 20 | 824081 | SET SCREW (#10-32) | ACT | $1.00 | $0.98 | 1 | |||
| 21 | 12019 | CABLE ASSEMBLY | ACT | $155.92 | $146.83 | 1 | |||
| 22 | 8M0204660 | GUIDE | 43433 | SS |
|
$23.74 | $23.33 | 1 | |
| 23 | 20007 | ANCHOR | ACT | $28.67 | $28.15 | 1 | |||
| 24 | 8M0204644 | SET SCREW (#8-32) | 20518 | SS |
|
$1.80 | $1.76 | 2 | |
| 25 | 823567105 | SCREW (M10 x 105) Hex Flange - Stainless Steel | ACT | $11.60 | $11.32 | 1 | |||
| 26 | 48416 | CAP | ACT | $5.90 | $5.76 | 1 | |||
| 27 | 4002319 | WASHER | ACT | $3.20 | $3.13 | 1 | |||
| 28 | 12024 | WASHER (.402 x .787 x .039 Bellevi) | ACT | $5.90 | $5.76 | 1 | |||
| 29 | 146011 | SPACER | 14601 | SS |
|
$26.58 | $26.11 | 1 | |
| 30 | 812930A1 | BUSHING | ACT | $7.10 | $6.93 | 2 | |||
| 31 | 40140 | NUT (M10) | 13914 | SS |
|
$3.39 | $3.30 | 1 | |
| 38 | 68878A6 | HORN ASSEMBLY Buzzer Alarm | NLA |
|
$0.00 | $0.00 | 1 | ||
| 39 | 68879 | ----COVER | NLA |
|
$0.00 | $0.00 | 1 | ||
| 40 | 40056107 | SCREW (M5 x 16) | ACT | $4.00 | $3.91 | 2 |
