| Ref # | Current Part Nbr |
Description | Superceded From |
Status | Notes | List Price |
Online Price |
Quan Used |
Order Quan |
|---|---|---|---|---|---|---|---|---|---|
| 1 | 190503 | GASKET | ACT |
|
$28.99 | $28.48 | 1 | ||
| 2 | 827323A2 | PLATE Divider | 8185622 | SS |
|
$398.99 | $369.25 | 1 | |
| 3 | 814754 | SEAL (12.50 Inches) | ACT |
|
$11.09 | $10.83 | 1 | ||
| 4 | 814634 | CLAMP | ACT |
|
$5.09 | $4.98 | 4 | ||
| 5 | 8263561 | SCREW AND WASHER (.312-18 x 1.500) | 826356 | SS |
|
$1.90 | $1.86 | 20 | |
| 6 | 8144301 | FITTING (.500-14) | 814430 | SS |
|
$30.49 | $29.95 | 1 | |
| 7 | 920071 | FITTING (.250-18) (90_) | 92007 | SS |
|
$54.49 | $51.33 | 1 | |
| 8 | 8M0108355 | LINE (57.00 Inches Bulk) (Cut to 23.50 Inch Length) | 99127109 | SS |
|
$52.49 | $49.29 | 1 | |
| 9 | 816311T | TIE STRAP (8.00 Inches) | 816311 | SS |
|
$0.60 | $0.59 | 2 | |
| 10 | 8M0039767 | COVER Relief Valve | 68729 | SS |
|
$54.99 | $51.72 | 1 | |
| 11 | 74824 | SCREW (.312-18 x 1.250) | ACT |
|
$1.80 | $1.76 | 4 | ||
| 12 | 78690002 | GASKET | 78690 | SS |
|
$4.09 | $4.00 | 2 | |
| 13 | 69570 | SCREW (#10-16 x .750) | ACT |
|
$1.80 | $1.76 | 1 | ||
| 14 | 76451 | WASHER | ACT |
|
$2.79 | $2.72 | 1 | ||
| 15 | 144791 | DIAPHRAGM | 14479 | SS |
|
$17.59 | $17.27 | 1 | |
| 16 | 16496 | DEFLECTOR Water | ACT |
|
$4.09 | $4.00 | 1 | ||
| 17 | 16497A1 | PLATE | ACT |
|
$43.99 | $43.13 | 1 | ||
| 18 | 64878 | SPRING (Black) | ACT |
|
$6.79 | $6.64 | 1 | ||
| 19 | 85303 | WASHER | ACT |
|
$2.69 | $2.62 | 1 | ||
| 20 | 14480 | POPPET | ACT |
|
$10.69 | $10.44 | 1 | ||
| 21 | 64872 | GROMMET | ACT |
|
$3.59 | $3.50 | 1 | ||
| 22 | 65848 | CARRIER | ACT |
|
$3.59 | $3.50 | 1 | ||
| 23 | 991764 | GASKET | 991763 | SS |
|
$20.79 | $20.38 | 1 | |
| 24 | 18260T2 | PLATE ASSEMBLY Exhaust | 18260A2 | SS |
|
$551.49 | $501.93 | 1 | |
| 25 | 89772Q1 | ----CONNECTOR (.125-27) Straight | 897721 | SS |
|
$8.39 | $8.20 | 1 | |
| 26 | 43044 | ----PIN Dowel | 20033 | SS |
|
$2.49 | $2.43 | 2 | |
| 27 | 8M0043164 | ----SEAL | 8147011 | SS |
|
$49.49 | $48.36 | 1 | |
| 28 | 680101 | ----BRACKET | ACT | $11.19 | $10.93 | 1 | |||
| 29 | 878608 | ----SCREW (#10-16 x .500) | 812832 | SS |
|
$1.70 | $1.66 | 8 | |
| 30 | 20553 | WASHER (.406 x .734 x .06 | ACT | $1.50 | $1.47 | 6 | |||
| 31 | 69254 | NUT | ACT | $7.29 | $7.12 | 6 | |||
| 32 | 27132 | BUSHING | ACT | $4.74 | $4.65 | 1 | |||
| 33 | 8M0179867 | GROMMET | 19564 | SS |
|
$9.09 | $8.88 | 1 | |
| 34 | 12602002 | GROMMET | 126021 | SS |
|
$4.59 | $4.49 | 1 | |
| 34 | 19565002 | GROMMET | 19565 | SS |
|
$30.99 | $30.36 | 1 | |
| 35 | 66727 | SCREW (.312-18 x 1.250) | ACT | $2.99 | $2.92 | 1 | |||
| 36 | 68783 | SCREW (.312-18 x 2.50) | ACT | $6.69 | $6.54 | 1 | |||
| 37 | 898833 | SCREW (.375-16 x 3.50) | 66725 | SS/NLA |
|
$0.00 | $0.00 | 3 | |
| 38 | 812905T | BRACKET ASSEMBLY | 812905A3 | SS |
|
$168.99 | $152.36 | 1 | |
| 39 | 90285 | SCREW (.312-18 x .625) | ACT | $1.80 | $1.76 | 4 | |||
| 39A | 56720 | WASHER (.330 x .750 x .060) Stainless Steel | ACT | $1.80 | $1.76 | 4 | |||
| 40 | 187031 | WASHER | ACT | $4.99 | $4.88 | 4 | |||
| 41 | 18778001 | GROMMET | 18778 | SS |
|
$11.09 | $10.83 | 4 | |
| 42 | 18578T09 | BRACKET ASSEMBLY Rear | 18578A6 | SS |
|
$162.49 | $146.35 | 1 | |
| - | 815791A92 | GASKET SET Engine | NLA |
|
$0.00 | $0.00 | 1 |
