Ref # Current
Part Nbr		 Description Superceded
From		 Status Notes List
Price		 Online
Price		 Quan
Used		 Order
Quan
1 8M0188297 CYLINDER HEAD 881684 SS $2,443.75 $2,306.91 1
1 8M0188298 CYLINDER HEAD 881685 SS $2,443.75 $2,306.91 1
2 NSS --------NOT SOLD SEPARATE SEAT $0.00 $0.00
3 NSS --------NOT SOLD SEPARATE GUIDE-Valve $0.00 $0.00
4 881631 GASKET Cylinder Head ACT $207.92 $195.80 1
4 879150064 GASKET Cylinder Head 881632 SS $168.08 $158.29 1
5 881674 VALVE Intake ACT $65.25 $62.76 8
5 881675 VALVE Intake NLA $0.00 $0.00 AR
5 8M0107993 VALVE Intake 881676 SS $62.74 $60.36 AR
5 881677 VALVE Intake ACT $103.82 $97.78 AR
6 8M0133006 VALVE Exhaust 881678 SS $187.33 $176.42 8
6 881679 VALVE Exhaust NLA $0.00 $0.00 AR
6 881680 VALVE Exhaust ACT $89.33 $85.93 AR
6 881681 VALVE Exhaust ACT $89.00 $85.61 AR
7 850463 ROTATOR Valve ACT $43.42 $42.64 8
8 881637T SEAL Valve Stem Oil 881637 SS $29.42 $28.89 16
9 881672001 SPRING Valve 881672 SS $27.67 $27.17 16
10 850464 CAP Valve Spring ACT $19.92 $19.56 8
11 54530 KEY Valve Stem ACT $6.90 $6.73 32
12 850467 LIFTER Valve 850467T SS $114.33 $107.67 16
13 845754 GUIDE Valve Lifter ACT $8.10 $7.90 8
14 881682T PUSH ROD (Intake) 881682 SS $50.75 $48.82 8
14 881683 PUSH ROD (Exhaust) ACT $57.25 $55.07 8
15 881686 GUIDE Rocker Arm ACT $18.41 $17.95 8
16 881635 STUD ACT $37.00 $36.34 16
17 881687T ARM 881687 SS $99.84 $96.02 16
18 58041 BALL ACT $34.08 $33.47 16
19 801883 NUT ACT $19.00 $18.66 12
20 75983 PLUG ACT $8.20 $8.00 2
21 881642A01 SCREW (M10 x 52) 881625 NLA $0.00 $0.00 8
22 881642A01 SCREW (M10 x 86) 881624 NLA $0.00 $0.00 4
23 881642A01 SCREW (M10 x 103) 881642 NLA $0.00 $0.00 24
24 881622 GASKET Cylinder Head Cover ACT $76.17 $73.26 2
25 881671 COVER Cylinder Head NLA $0.00 $0.00 2
25 891870 COVER Cylinder Head ACT $310.08 $292.01 2
26 881621 GASKET ACT $30.24 $29.71 14
27 881623 SCREW (M6 x 1) ACT $32.92 $32.33 14
28 881721001 HARNESS ASSEMBLY Ignition Coil Wiring 881721 SS/NLA $0.00 $0.00 1
28 8M0143829 HARNESS ASSEMBLY Ignition Coil Wiring 891886 SS $57.58 $55.39 1
29 8M0157899 BOLT (M6 x 13) 881648 SS $26.00 $25.53 4
30 8M0069809 CLIP Wiring Harness 881722 SS $5.10 $4.98 2
31 881724 CONNENCTOR Ignition Coil to Wiring Harness NLA $0.00 $0.00 4
32 881723 CONNENCTOR Harness to Harness NLA $0.00 $0.00 1
33 8M0187403 COIL Ignition 881732 SS $264.50 $249.08 8
33 8M0178581 COIL Ignition 889925 SS $220.49 $207.41 8
34 881647 SCREW ACT $19.08 $18.74 16
35 8M0220181 WIRE KIT (8 Leads) Spark Plug 881698 SS $592.99 $557.83 1
35 888740 ----WIRE Individual Spark Plug NLA $0.00 $0.00 4
35 8M0119695 ----WIRE Individual Spark Plug 888741 SS $189.08 $178.06 4
36 8M0129146 SPARK PLUG 863622 SS $24.49 $24.04 8
NS 881720 RETAINER (2 Spark Plug Wire) NLA $0.00 $0.00 AR
NS 883924 RETAINER (Conduit) ACT $6.40 $6.25 AR
