| Ref # | Current Part Nbr |
Description | Superceded From |
Status | Notes | List Price |
Online Price |
Quan Used |
Order Quan |
|---|---|---|---|---|---|---|---|---|---|
| 1 | 57969A12 | CYLINDER ASSY (25- 58224A 1 Repair Kit) | NLA |
|
$0.00 | $0.00 | 1 | ||
| 2 | 92054 | TUBE-EXTENDING | ACT | $76.99 | $72.20 | 1 | |||
| 3 | 92055 | TUBE-RETRACTING | ACT | $91.99 | $86.25 | 1 | |||
| 4 | 94953A1 | BRACKET ASSY | NLA |
|
$0.00 | $0.00 | 1 | ||
| 7 | 8M0113173 | BOLT-PIVOT | 42253 | SS |
|
$30.49 | $29.87 | 2 | |
| 8 | 42254 | WASHER-TAB | ACT | $5.39 | $5.27 | 2 | |||
| 9 | 88282 | SLEEVE | NLA |
|
$0.00 | $0.00 | 1 | ||
| 10 | 816458A1 | VALVE ASSY (25- 58226A 1 Seal Repair Kit) | NLA |
|
$0.00 | $0.00 | 1 | ||
| 11 | 88280 | ADAPTOR | NLA |
|
$0.00 | $0.00 | 1 | ||
| 12 | 37612 | SCREW | ACT | $2.49 | $2.43 | 1 | |||
| 13 | 35048 | LOCKWASHER | ACT | $1.20 | $1.18 | 1 | |||
| 14 | 67305 | FITTING Old Design | NLA |
|
$3.10 | $3.03 | 1 | ||
| 15 | 88281 | SCREW | NLA |
|
$0.00 | $0.00 | 1 | ||
| 16 | 20959 | WASHER | ACT | $2.59 | $2.53 | 1 | |||
| 17 | 88285 | ADAPTOR | NLA |
|
$0.00 | $0.00 | 1 | ||
| 18 | 8M0207779 | LOCKWASHER | 76629 | SS |
|
$8.29 | $8.10 | 1 | |
| 19 | 55111 | NUT | NLA |
|
$0.00 | $0.00 | 1 | ||
| 20 | 96511 | TUBE ASSY | 96511A1 | SS |
|
$94.99 | $89.39 | 1 | |
| 21 | 88287 | GUIDE | NLA |
|
$0.00 | $0.00 | 1 | ||
| 22 | 32882 | NUT | ACT | $9.49 | $9.27 | 1 | |||
| 23 | 95848A1 | CLEVIS ASSY | NLA |
|
$0.00 | $0.00 | 1 | ||
| 24 | 20086 | WASHER | ACT | $1.70 | $1.66 | 1 | |||
| 25 | 69254 | NUT | ACT | $7.29 | $7.12 | 1 | |||
| 26 | 95803 | BUSHING | ACT | $18.19 | $17.84 | 2 | |||
| 27 | 88283 | PIN | NLA |
|
$0.00 | $0.00 | 2 | ||
| 28 | 88286 | BUSHING | NLA |
|
$0.00 | $0.00 | 1 | ||
| 29 | 92766 | LOCK | NLA |
|
$0.00 | $0.00 | 1 | ||
| 30 | 41209 | SCREW | NLA |
|
$0.00 | $0.00 | 1 | ||
| 31 | 89229 | PIN-CLEVIS | ACT | $7.39 | $7.22 | 1 | |||
| 32 | 52798 | PIN-CLEVIS | ACT | $7.49 | $7.32 | 1 | |||
| 33 | 46950 | PIN-COTTER | ACT | $4.19 | $4.10 | 2 | |||
| 34 | 35462 | WASHER | ACT | $1.80 | $1.76 | 1 | |||
| 35 | 54929 | PIN-COTTER | 34212 | SS |
|
$7.89 | $7.71 | 1 | |
| 36 | 8M0208403 | ACTUATOR ASSY Complete Parts are Not Sold Separate at This Time (New Design) | 806034A2 | SS |
|
$1,628.49 | $1,458.38 | 1 |
