Ref # Current
Part Nbr		 Description Superceded
From		 Status Notes List
Price		 Online
Price		 Quan
Used		 Order
Quan
- 8M0176290 REMOTE CONTROL Power Trim, Side Mount 15 ft (Molex) 8M0103449 SS $539.86 $499.49 1
- 8M0176291 REMOTE CONTROL Power Trim 20 ft (Molex) 8M0103450 SS $553.13 $510.17 1
- 8M0176294 REMOTE CONTROL Power Trim 15 ft (8 Pin) 8M0103452 SS $540.28 $499.49 1
- 8M0176295 REMOTE CONTROL Power Trim 20 ft (8 Pin) 8M0103453 SS $553.55 $510.17 1
- 8M0103451 REMOTE CONTROL Non Trim 15 ft, Warning Horn (Molex) ACT $522.27 $483.64 1
- 8M0103454 REMOTE CONTROL Non Trim 15 ft (8 Pin) ACT $522.38 $483.64 1
- 8M0176297 REMOTE CONTROL Side Mount -Power Trim 15 feet (14 Pin) 8M0121856 REP $558.86 $515.36 1
1 8M0100485 ----HANDLE ASSEMBLY Non Trim NLA $0.00 $0.00 1
2 8M0086976 --------PLUG Handle - Remote Control ACT $1.22 $1.20 1
3 8M0083671 --------GRIP Handle ACT $8.93 $8.78 1
4 NSS ----------------NOT SOLD SEPARATE Handle Hub $0.00 $0.00 1
5 8M0192342 --------LOCK BAR Remote Control 8M0083673 SS $6.47 $6.35 1
6 8M0099569 --------SCREW (M4 x 8) ACT $0.68 $0.67 1
7 16924 --------SPRING ACT $1.54 $1.51 1
8 858686 --------SCREW (#8) ACT $1.20 $1.18 2
9 8M0083674 --------RETAINER Lock Bar Remote Control ACT $13.31 $13.05 1
10 8M0100486 ----CAP AND DECAL ACT $6.17 $6.04 1
11 8222131 ----BOLT ACT $5.94 $5.83 1
12 8M0214461 ----HANDLE ASSEMBLY With Trim 8M0100483 SS $84.49 $81.83 1
13 8M0100481 --------TRIM SWITCH ASSEMBLY ACT $17.48 $17.14 1
14 8M0083671 --------GRIP Handle ACT $8.93 $8.78 1
15 NSS ----------------NOT SOLD SEPARATE Handle Hub $0.00 $0.00 1
16 8M0192342 --------LOCK BAR Remote Control 8M0083673 SS $6.47 $6.35 1
17 8M0099569 --------SCREW (M4 x 8) ACT $0.68 $0.67 1
18 16924 --------SPRING ACT $1.54 $1.51 1
19 858686 --------SCREW (#8) ACT $1.20 $1.18 2
20 8M0083674 --------RETAINER Lock Bar Remote Control ACT $13.31 $13.05 1
21 8M0120604 ----HOUSING ASSEMBLY Remote Control (with Decal) ACT $217.26 $204.57 1
22 8M0210763 ----ALARM ASSEMBLY Audio Warning 8M3001068 SS $55.74 $53.63 1
23 11083A4 ----SWITCH ASSEMBLY Stop ACT $59.00 $56.75 1
24 8M0164890 ----LANYARD CORD ASSEMBLY 54 8M0092849 SS $18.83 $18.42 1
24 8M0164891 ----LANYARD CORD ASSEMBLY 54 8M0092850 SS $18.83 $18.42 1
25 8M0055593 ----GROMMET ACT $0.89 $0.88 1
26 8M0133558 ----KEY SWITCH ASSEMBLY With Choke ACT $90.89 $88.38 1
27 8M0207779 --------LOCKWASHER Internal Tooth (.750) 76629 SS $7.70 $7.51 1
28 897716001 --------NUT Plastic-Key Switch ACT $5.80 $5.70 1
29 8M0088358 ----SCREW SS (M4 x 0.7x 20) ACT $0.15 $0.15 6
30 NSS --------NOT SOLD SEPARATE Upper / Lower Back, Housing $0.00 $0.00 1
31 8M0114782 ----SPACER Side Mount Remote Control ACT $28.17 $27.68 1
32 8M0204698 ----SCREW (#8-32 x .375) 859665 SS $2.60 $2.54 1
33 401196 ----NUT (M6) ACT $2.98 $2.92 3
34 8M0088358 ----SCREW SS (M4 x 0.7x 20) ACT $0.15 $0.15 3
35 40116110T ----SCREW SS (M6 x 120) 8M0094609 REP $4.47 $4.37 3
36 35280 ----WASHER (.255 x .620 x .030) Stainless Steel ACT $3.20 $3.13 3
37 8M2100450 ----HARNESS ADAPTER Neutral, Female NLA $0.00 $0.00 1
38 8M2100451 ----HARNESS ADAPTER Neutral, Male NLA $0.00 $0.00 1
39 816311T ----TIE STRAP (8.00 Inches) ACT $0.59 $0.58 3
40 899145 ----CLIP Tie Strap ACT $3.40 $3.32 2
41 8M0120598 ----TRIM HARNESS 15 feet (8 Pin) ACT $107.85 $101.55 1
41 8M0120599 ----TRIM HARNESS 20 feet (8 Pin) ACT $120.61 $113.57 1
42 8M0120595 ----TRIM HARNESS 15 feet (Molex) ACT $110.10 $103.67 1
42 8M0120596 ----TRIM HARNESS 20 feet (Molex) ACT $122.84 $115.71 1
43 8M0120597 ----HARNESS NON TRIM 15 feet (Molex) ACT $107.19 $100.96 1
44 8M0120600 ----HARNESS NON TRIM 15 feet (8 Pin) ACT $99.20 $95.15 1
45 8M0143202 TRIM HARNESS 15 feet (14 Pin) 8M0124025 REP $194.98 $183.57 1
45 8M0143203 TRIM HARNESS 20 feet (14 Pin) 8M0124026 NLA $0.00 $0.00 1
