Ref # Current
Part Nbr		 Description Superceded
From		 Status Notes List
Price		 Online
Price		 Quan
Used		 Order
Quan
1 F1107 FILL HD SCREW, 1/4 - 20 X 3/4 NLA $0.00 $0.00 4
2 F458146 SEAL, CRANKSHAFT UPPER MAIN NLA $0.00 $0.00 1
3 FA458144 CRANKSHAFT BEARING CAGE NLA $0.00 $0.00 1
4 F458277 GASKET, CRANKSHAFT BEARING CAGE NLA $0.00 $0.00 1
5 817833A1 MAGNETO STATOR RING FA504082 SS $0.00 $0.00 1
6 F1727 PLASTI-RIVET NLA $0.00 $0.00 1
7 NSS CYLINDER W/CRANKCASE COVER, SCREWS AND DOWEL PINS $0.00 $0.00 1
- NSS SHORT BLOCK FOR HAND START MODELS (NOT SHOWN) $0.00 $0.00 1
- FC505010 SHORT BLOCK FOR ALTERNATOR MODELS (NOT SHOWN) NLA $0.00 $0.00 1
8 F184122-1 SEAL, CRANKCASE PARTING LINE F269122-1 SS $20.70 $20.19 1
9 28636 HEX SLOTTED HD SCREW, 1/4 - 20 X 3/4 F1864 SS $1.80 $1.76 8
10 F2005 HEX SOCKET HD CAP SCREW, 5/16 - 18 X 2 3/4 NLA $0.00 $0.00 2
13 8M0204690 PLAIN WASHER, FOR HAND START MODELS F1739 SS $1.80 $1.76 10
- 8M0204690 PLAIN WASHER, FOR ELECTRIC START MODELS F1739 SS $1.80 $1.76 7
14 47819 HEX SOCKET HD CAP SCREW, 5/16 - 18 X 1 1/4 F2013 SS $0.00 $0.00 4
15 F8559 DOWEL PIN NLA $0.00 $0.00 1
17 FA458254 HOSE, DRAIN NLA $0.00 $0.00 1
18 F366801 FITTING NLA $0.00 $0.00 1
19 F85026 SWIVEL, SHIFT INTERLOCK LEVER NLA $0.00 $0.00 1
20 26841 BEARING F307818 SS $7.59 $7.42 1
21 F458977-3 LEVER, SHIFT INTERLOCK NLA $0.00 $0.00 1
22 816514 BEARING, SHIFT INTERLOCK ROD F84035-2 SS $0.00 $0.00 1
23 819625 SWIVEL, SHIFT INTERLOCK BEARING F84026 SS $0.00 $0.00 1
24 817805A1 ROD, SHIFT INTERLOCK F458531 SS $0.00 $0.00 1
25 82670912 LOCK NUT, 3/8 - 16 F7004 SS $6.80 $6.64 1
26 F98273 ROD END CONNECTOR STUD NLA $11.21 $10.93 2
27 F8058 INTERNAL TOOTH LOCKWASHER NLA $0.00 $0.00 8
28 F269052 BEARING, SHIFT LEVER NLA $0.00 $0.00 2
29 817808A2 LEVER, GEAR SHIFT NLA $0.00 $0.00 1
30 68219 HEX NUT, 10 - 32 F1513 SS $3.00 $2.93 6
31 8263872 STUD, GEAR SHIFT LEVER F440209 SS $0.00 $0.00 1
32 F436314-1 ELBOW, DRAIN HOSE NLA $0.00 $0.00 1
33 F1922 HEX HD SCREW, 1/4 - 20 X 5/8 NLA $0.00 $0.00 1
34 FA504222 TRANSFER PORT COVER NLA $0.00 $0.00 1
35 817741A1 CHECK VALUE NLA $0.00 $0.00 2
36 F429811 SCREEN, CYLINDER DRAIN ACT $1.10 $1.08 2
37 819413 GASKET, TRANSFER PORT COVER F458223 SS $0.00 $0.00 1
38 F458529 GASKET, CYLINDER HEAD NLA $0.00 $0.00 1
39 FA458518 CYLINDER HEAD W/PLUGS NLA $0.00 $0.00 1
40 F458109 PLUG, CYLINDER HEAD NLA $0.00 $0.00 2
41 F1882 SCREW, CYLINDER HEAD F458936 SS $0.00 $0.00 10
42 896323 SPARK PLUG (L-4-J) FS174227 SS $6.39 $6.25 2
- FC235227 SPARK PLUG - CANADA (RL-4J) HAND START MODELS NLA $0.00 $0.00 2
- 896329828 SPARK PLUG - CANADA QL-77J4 FOR ELECTRIC START MODELS FC503227 SS $12.10 $11.80 2
43 28635 HEX CAP SCREW, 1/4 - 20 X 5/8 F1854 SS $1.80 $1.76 2
44 F458066 THERMOSTAT COVER NLA $0.00 $0.00 1
45 F458067 GASKET, THERMOSTAT COVER NLA $0.00 $0.00 1
46 819478 GASKET, EXHAUST PORT PLATE F458154 SS $0.00 $0.00 2
47 F458151 EXHAUST PORT PLATE NLA $0.00 $0.00 1
48 F458152-1 EXHAUST PORT COVER F458152 SS $0.00 $0.00 1
49 819110100 HEX HD SCREW, 1/4 - 20 X 1 F1833 SS $0.50 $0.49 10
50 F1072 FILL HD SCREW, 1/4 - 20 X 1 3/4 NLA $0.00 $0.00 1
51 F458445 LINK, MAGNETO CONTROL SHAFT (MANUAL START MODELS) NLA $0.00 $0.00 1
52 F286440 STUD, MAGNETO CONTROL LEVER NLA $0.00 $0.00 1
53 F183813 BEARING NLA $0.00 $0.00 1
54 F2A458081 MAGNETO CONTROL LEVER W/CONNECTOR STUD NLA $0.00 $0.00 1
55 F286282 WASHER NLA $0.00 $0.00 1
56 F1803 STOP NUT NLA $0.00 $0.00 1
57 828514A1 JOINT BALL ASSEMBLY 8177471 SS $22.08 $21.69 2
58 F458509 LINK, MAGNETO STATOR NLA $0.00 $0.00 1
59 F458502 ROD, THROTTLE CAM NLA $0.00 $0.00 1
60 8267088 LOCK NUT F1910 SS $1.70 $1.66 1
61 F269319 BEARING, THROTTLE CAM NLA $0.00 $0.00 2
62 F458192-1 THROTTLE CAM F458192 SS $0.00 $0.00 1
63 F433209-1 STUD, THROTTLE CAM F433209 SS $0.00 $0.00 1
64 F504809 ROD, STARTER INTERLOCK NLA $0.00 $0.00 1
65 96202 BEARING F504052 SS $0.00 $0.00 2
66 F504527 CAP, INTERLOCK NLA $0.00 $0.00 1
67 F1090 FILL HD M. SCREW, 10 - 24 X 1/2 F1075 SS $0.00 $0.00 2
68 98254 HEX CAP SCREW, 1/4 - 20 X 5/8 F1502 SS $0.60 $0.59 9
69 64015 HEX NUT F1341 SS $2.81 $2.75 1
70 F460317-2 CLAMP, CHOKE SOLENOID ELECTRIC START MODELS F460317 SS $0.00 $0.00 1
71 73286 HEX CAP SCREW, 1/4 - 20 X 1/2 ELECTRIC START MODELS F1689 SS $1.80 $1.76 2
72 34931 PLAIN WASHER F2014 SS $2.60 $2.54 1
73 F458727 BALL SHIFT LEVER DETENT NLA $0.00 $0.00 1
74 F183300 SPRING, SHIFT DETENT NLA $0.00 $0.00 1
75 F8000 PLAIN WASHER NLA $0.00 $0.00 1
76 FG1010 GASKET SET NLA $0.00 $0.00 1
- 828925 GASKET, CARBURETOR F40906-1 SS $2.39 $2.33 1
- F433168 GASKET, CARBURETOR ADAPTER ACT $2.70 $2.64 1
- F433406 DEFLECTOR PLATE GASKET ACT $5.10 $4.98 1
- 823606 FUEL PUMP BOWL GASKET F438617 SS $14.90 $14.53 1
- 820490 FUEL PUMP GASKET F438760 SS $4.60 $4.49 1
- F458067 THERMOSTAT COVER GASKET NLA $0.00 $0.00 1
- 819478 EXHAUST PORT PLATE F458154 SS $0.00 $0.00 2
- 819413 TRANSFER PORT COVER GASKET F458223 SS $0.00 $0.00 1
- F458277 CRANKSHAFT BEARING CAGE GASKET NLA $0.00 $0.00 1
- F458279 CYLINDER EXHAUST GASKET NLA $0.00 $0.00 1
- F458453 LEG EXHAUST GASKET NLA $0.00 $0.00 1
- F458529 CYLINDER HEAD GASKET NLA $0.00 $0.00 1
