| Ref # | Current Part Nbr |
Description | Superceded From |
Status | Notes | List Price |
Online Price |
Quan Used |
Order Quan |
|---|---|---|---|---|---|---|---|---|---|
| 0-1 | 80927M | FLYWHEEL MAGNETO ASSY | NLA |
|
$0.00 | $0.00 | 1 | ||
| 1 | 80560M | FLYWHEEL | NLA |
|
$0.00 | $0.00 | 1 | ||
| 2 | 80928M | --BASE, MAGNETO | NLA |
|
$0.00 | $0.00 | 1 | ||
| 3 | 80551M | INGNITION COIL,#1 CYL.(TOP) | NLA |
|
$0.00 | $0.00 | 1 | ||
| 4 | 80552M | --IGNITON COIL,#2CYL.(BOTTOM) | NLA |
|
$0.00 | $0.00 | 1 | ||
| 5 | 80556M | SCREW,COIL ATTACHING | NLA |
|
$0.00 | $0.00 | 2 | ||
| 6 | 80555M | SPACER,COIL | NLA |
|
$0.00 | $0.00 | 2 | ||
| 7 | 80553M | --LIGHTING,COIL | NLA |
|
$0.00 | $0.00 | 1 | ||
| 8 | 82522M | --SCREW,COIL ATTACHING | 80557M | SS |
|
$0.00 | $0.00 | 2 | |
| 9 | 80930M | --BREAKER ASSY | ACT | $73.33 | $70.54 | 2 | |||
| 10 | 82500M | --SCREW | 80023M | SS |
|
$0.00 | $0.00 | 4 | |
| 11 | 82206M | --LOCK WASHER | 82184M | SS |
|
$0.00 | $0.00 | 4 | |
| 12 | 80558M | --CONDENSER | ACT | $35.33 | $34.70 | 2 | |||
| 13 | 80025M | --LUBRICATOR | NLA |
|
$0.00 | $0.00 | 2 | ||
| 14 | 80559M | --GROMMET, MAGNETO BASE | NLA |
|
$0.00 | $0.00 | 1 | ||
| 15 | 80929M | --LEAD WIRE | NLA |
|
$0.00 | $0.00 | 1 | ||
| 16 | 80763M | CAM, THROTTLE ADVANCE | NLA |
|
$0.00 | $0.00 | 1 | ||
| 17 | 82417M | BOLT, CAM ATTACHING | NLA |
|
$0.00 | $0.00 | 2 | ||
| 18 | 82211M | WASHER, CAM BOLT | 82196M | SS |
|
$5.56 | $5.43 | 2 | |
| 19 | 80767M | STOP, MAGNETO BASE | NLA |
|
$0.00 | $0.00 | 1 | ||
| 20 | 826957M | BOLT, STOP ATTACHING | 82422M | SS |
|
$0.00 | $0.00 | 2 | |
| 21 | 82214M | WASHER | 82199M | SS |
|
$5.93 | $5.78 | 6 | |
| 22 | 81878M | PIN, MAGNETO CONTROL LEVER | NLA |
|
$0.00 | $0.00 | 1 | ||
| 23 | 82647M | RETAINER, MAGNETO BASE-OUTER | NLA |
|
$0.00 | $0.00 | 1 | ||
| 23 | 81047M | RETAINER, MAGNETO BASE-OUTER | NLA |
|
$0.00 | $0.00 | 1 | ||
| 24 | 82648M | RETAINER, MAGENTO BASE-INNER | NLA |
|
$0.00 | $0.00 | 1 | ||
| 24 | 81048M | RETAINER, MAGNETO BASE-INNER | NLA |
|
$0.00 | $0.00 | 1 | ||
| 25 | 83523M | SCREW, RETAINER ATTACHING | 82490M | SS |
|
$0.00 | $0.00 | 3 | |
| 26 | 82186M | LOCK WASHER, RETAINER SCREW | 82193M | SS |
|
$0.00 | $0.00 | 3 | |
| 27 | 81769M | NUT, FLYWHEEL ATTACHING | NLA |
|
$0.00 | $0.00 | 1 | ||
| 28 | 81805M | WASHER, FLYWHEEL NUT | NLA |
|
$0.00 | $0.00 | 1 | ||
| 29 | 80931T | SECONDARY IGNITION COIL ASS'Y | 80931M | SS |
|
$0.00 | $0.00 | 2 | |
| 30 | 82831M | --LEAD, HIGH TENSION | NLA |
|
$0.00 | $0.00 | 2 | ||
| 31 | 83285M | BOLT, COIL ATTACHING | 82426M | SS |
|
$4.59 | $4.49 | 4 | |
| 32 | 63709A1 | PLUG CAP | 80183M | SS |
|
$8.20 | $8.00 | 2 | |
| 32 | 63709A1 | PLUG CAP | 82788M | SS |
|
$8.20 | $8.00 | 2 | |
| 32 | 815119M | PLUG CAP, NOISE SUPPRESSOR (OPTIONAL) | 80935M | SS |
|
$0.00 | $0.00 | 2 | |
| 32 | 63709A1 | PLUG CAP (OPTIONAL) | 80274M | SS |
|
$8.20 | $8.00 | 2 |
